Shorts SC.7 Skyvan
The box-fuselage utility transport. Almost all of the 150 built were Series 3s, including about 60 military 3Ms.
Download PDFPowerplant
- Engines
- 2 × Garrett TPE331-2-201A, 535 kW (715 shp), Hartzell three-blade
Performance
- Max cruise
- 324 km/h (175 kt)
- Normal cruise
- 311 km/h (168 kt)
- Initial climb
- 1,640 ft/min
- Ceiling
- 22,500 ft
Weights
- Basic operating
- 3,331 kg (7,344 lb)
Dimensions
- Span
- 19.79 m (64 ft 11 in)
- Length
- 12.21 m (40 ft 1 in)
- Height
- 4.60 m (15 ft 1 in)
- Wing area
- 35.1 m² (378 sq ft)
Capacity & production
- Seating
- Up to 19, or nine in executive layout
- Built
- 150 Skyvans and Skyliners, mid-1960s to 1987
